Direct Digital Shear Apparatus

Digital direct shear box, floor mounted with carriage assembly and load hanger with 10:1 lever loading device.

To accept the following sample sizes:

  • 60mm diameter
  • 60mm square
  • 100mm diameter
  • 100mm square
  • 2.5 inch diameter

Features

  • Microprocessor controlled digital stepper motor
  • Control via the digital display with keyboard
  • Return datum facility
  • Fully steplessly variable speed over the range of 0.00001 to 9.99999mm/minute
  • RS232 port
  • Forward/reverse travel limit switches
  • Will accept either analogue or digital measuring devices
